Name: Rotin Pathfinder Pro (Europe)
Brand: Rattan
SKU: LFPRO-WH
Price: 1199.0 EUR
Availability: InStock

Test Ride

Offre limitée - Accessoire GRATUIT (valeur jusqu'à 268 $) à l'achat de tout vélo électrique

Ask a Ride Consultant

Panier

Votre panier est vide

Commencez vos achats

FAQs

Does the LF Pro 2026 comply with European road regulations for e-bikes?

Yes. Our European-version e-bikes fully comply with EU road-use requirements. They are CE certified and meet the EN 15194 standard, which is the European safety and performance standard specifically for electrically power-assisted cycles (EPACs).

This ensures the bike meets all necessary regulations for electrical safety, mechanical safety, and electromagnetic compatibility, making it legal for road use across Europe.

How do I assemble my ebike? Will it be difficult?

Rattan LF Pro e-bike is 85% assembly. Use the configured tools to complete the remaining assembly operations according to the easy-to-follow manual. You can assemble it refer to the unboxing video.

Can I take a passenger? What is the maximum payload?

Yes, LF Pro comes with a rear seat, footrest, and backrest to carry passengers. The maximum payload is 180kg.

What is the max torque?

The max torque of pathfinder electric bike is 120N.M

ls it possible for me to ride this bike if my height is under 160cm?

Yes, you can ride the bike, it will be no problem for you to ride, but it would be a little high to step on the ground when you stop the bike.

What is the warranty?

Rattan offers a one-year warranty on all e-bikes, for more specific warranties, please check our warranty policy.

What's your shipping policy?

We ship from our warehouse in the EU, and your order typically arrives within 3-10 days. For more information, please visit our Shipping Policy.

More Questions?

We're here to help!

Contact us for any reason at: info@rattanebike.com

High-Torque Efficient E-Bike Motor

Powerful Performance Meets Reliable Long-Term Use

LF PRO

Powerful Hub Motor

With 120 N·m peak torque, the motor easily tackles 30° climbs and 180 kg loads, delivering instant, smooth power for confident riding on rough terrain with less fatigue. Its 90%+ energy conversion efficiency extends battery range by up to 15% compared to standard motors, while high-grade components ensure 10,000+ working hours of reliable, low-maintenance performance. Operating at ≤55 dB, it remains quieter than normal conversation, and the 5-level assist system responds seamlessly to your riding rhythm for a refined, comfortable ride.

25 km/h

Top Speed

120 N·m

Max Torque

90 %+

energy conversion efficiency

30 degree

Hill

LF PRO Powerful Hub Motor

With 120 N·m peak torque, the motor easily tackles 30° climbs and 180 kg loads, delivering instant, smooth power for confident riding on rough terrain with less fatigue. Its 90%+ energy conversion efficiency extends battery range by up to 15% compared to standard motors, while high-grade components ensure 10,000+ working hours of reliable, low-maintenance performance. Operating at ≤55 dB, it remains quieter than normal conversation, and the 5-level assist system responds seamlessly to your riding rhythm for a refined, comfortable ride.

25 km/h

Top Speed

120 N·m

Max Torque

90 %+

energy conversion efficiency

30 degree

Hill

18Ah High-Capacity Integrated Battery

Enjoy up to 120 km per charge with sleek in-frame design and protected charging

864 Wh

48V 18Ah

The high-capacity 18Ah battery delivers an impressive 80–120 km range per charge (depending on terrain and assist level), far exceeding standard 13–15Ah batteries. Its integrated in-frame design enhances the bike’s clean, streamlined look while improving weight balance and aerodynamics for a more stable ride. Equipped with a smart BMS, it ensures safer, more efficient charging by protecting against overcharge and overheating, extending battery life to 800+ charge cycles.

120 KM

Per Charge (maximum)

800+ times

Charge cycles

6 Protect

BMS

IEC 62133-2

Lithium Battery Safety Certification

864 Wh 48V 18Ah

The high-capacity 18Ah battery delivers an impressive 80–120 km range per charge (depending on terrain and assist level), far exceeding standard 13–15Ah batteries. Its integrated in-frame design enhances the bike’s clean, streamlined look while improving weight balance and aerodynamics for a more stable ride. Equipped with a smart BMS, it ensures safer, more efficient charging by protecting against overcharge and overheating, extending battery life to 800+ charge cycles.

120 KM

Per Charge (maximum)

800+ times

Charge cycles

6 Protect

BMS

IEC 62133-2

Lithium Battery Safety Certification

Hydraulic Front Fork for Smooth, Controlled Riding

80mm travel absorbs 70% of shocks, long-lasting durability for any terrain.

Hydraulic Front Fork

with adjustable damping

The hydraulic front fork with 80 mm travel absorbs road impacts effectively, reducing vibration by up to 70% for a noticeably smoother ride on rough terrain. With lockout and preload adjustment, riders can precisely tune the suspension to match different surfaces, from city streets to off-road trails. Constructed with aluminum alloy stanchions and a sealed hydraulic system, it is tested for 50,000+ compression cycles, delivering durable, low-maintenance performance and long-term stability.

80 mm

Travel

50,000+ times

Compression Cycles

70%

Vibration Reduction

30% improve

Handling Stability

Hydraulic Front Fork with adjustable damping

The hydraulic front fork with 80 mm travel absorbs road impacts effectively, reducing vibration by up to 70% for a noticeably smoother ride on rough terrain. With lockout and preload adjustment, riders can precisely tune the suspension to match different surfaces, from city streets to off-road trails. Constructed with aluminum alloy stanchions and a sealed hydraulic system, it is tested for 50,000+ compression cycles, delivering durable, low-maintenance performance and long-term stability.

80 mm

Travel

50,000+ times

Compression Cycles

70%

Vibration Reduction

30% improve

Handling Stability

180mm Hydraulic Disc Brakes

Powerful Stopping Performance

Hydraulic Disc Brakes

3 meters shorter stopping distance

The front and rear 180 mm hydraulic disc brakes deliver up to 25% stronger stopping power than standard 160 mm rotors, providing confident control during sudden stops and steep descents. A dual-piston hydraulic system ensures 4× better modulation and shortens stopping distance by 2–3 meters compared to mechanical brakes, maintaining stability at all times. With a sealed IPX5-rated design and durability tested for 10,000+ braking cycles, the system delivers reliable, low-maintenance performance in rain, mud, or snow.

180 mm

Disc Brakes

1 second

Brake Power Off

2 disc brakes

Front and back disc brakes

3 meters

Braking Distance

Hydraulic Disc Brakes 3 meters shorter stopping distance

The front and rear 180 mm hydraulic disc brakes deliver up to 25% stronger stopping power than standard 160 mm rotors, providing confident control during sudden stops and steep descents. A dual-piston hydraulic system ensures 4× better modulation and shortens stopping distance by 2–3 meters compared to mechanical brakes, maintaining stability at all times. With a sealed IPX5-rated design and durability tested for 10,000+ braking cycles, the system delivers reliable, low-maintenance performance in rain, mud, or snow.

180 mm

Disc Brakes

1 second

Brake Power Off

2 disc brakes

Front and back disc brakes

3 meters

Braking Distance

20×4.0 All-Terrain Fat Tires

Superior Traction on Any Surface

20"x4"

All Terrain

The 4.0-inch wide tires deliver up to 35% more ground contact than standard tires, ensuring strong, confident grip on sand, snow, gravel, and wet roads. Their high-volume construction reduces vibration by up to 60%, smoothing out bumps, rocks, and uneven surfaces for a more comfortable ride. With a wider footprint that boosts balance and cornering stability by 25%, these tires also provide reliable support for heavier loads, making them ideal for both daily commuting and off-road adventures.

Gravel Road

Highway

Mountain Trail

Dirt Road

Wetland

Snowy Road

20"x4" All Terrain

The 4.0-inch wide tires deliver up to 35% more ground contact than standard tires, ensuring strong, confident grip on sand, snow, gravel, and wet roads. Their high-volume construction reduces vibration by up to 60%, smoothing out bumps, rocks, and uneven surfaces for a more comfortable ride. With a wider footprint that boosts balance and cornering stability by 25%, these tires also provide reliable support for heavier loads, making them ideal for both daily commuting and off-road adventures.

Gravel Road

Highway

Mountain Trail

Dirt Road

Wetland

Snowy Road

Durable Folding Frame

Easy Transport and Storage

The folding frame design allows the bike to be compacted in under 10 seconds, reducing its size by over 50% for easy storage in car trunks, apartments, or office spaces. Its reinforced hinge structure is tested for 20,000+ fold cycles, ensuring long-term durability without compromising strength or stability. Perfect for commuters and travelers who need maximum portability.

180 kg

Payload Capacity

6061 aluminum

Material

10 seconds

Folding time

20,000+ times

Fold cycles

The folding frame design allows the bike to be compacted in under 10 seconds, reducing its size by over 50% for easy storage in car trunks, apartments, or office spaces. Its reinforced hinge structure is tested for 20,000+ fold cycles, ensuring long-term durability without compromising strength or stability. Perfect for commuters and travelers who need maximum portability.

180 kg

Payload Capacity

6061 aluminum

Material

10 seconds

Folding time

20,000+ times

Fold cycles

Multifunctional Display

Rattan Ebikes custom color display with Energy indicator,pedal assist level / Speedometer, Odometer/headlight/walk mode and more.

Soft Rear Seat

Provides convenience and safety for carrying a person on the back.

Leather Seat

Comfort saddle seat ensures you a stable and soft riding.

Full fender

Full fenders protect you from water and dirt splashing off the wheels.

Bright Front & Rear light

Bright front & rear lighting system ensures 360°visibility andsafer riding day or night.

Shimano 7-Speed

Shift to a larger gear for uphill riding and downshift to a smaller gear for high-speed riding.

Sizing

Overall Size
Folding Size
Height & Load

A
Total length

180cm

B
Wheelbase

122cm

C
Min seat height

80cm

D
Max seat height

100cm

E
Reach

55cm

F
Max handlebar height

135cm

G
Min handlebar height

120cm
A
Height

86cm

B
Length

103cm

C
Width

47cm
A
Recommend height

160cm - 195cm

B
Load capacity

180kg

Reliable service and support.

Want to learn more about the Rattan service Checkout our Services and support.

Free Shipping

Orders will be processed within 48 business hours.

Learn More

15 Days Trial

Accept returns within fifteen (15) days of delivery. Click here for more information.

Learn More

1-Year Warranty

We provide 1-year warranty for all the electrical components.

Learn More

CE Certified

Our Bikes are all meeting the standard of CE certification.

Learn More

Free Shipping

Orders will be processed within 48 business hours.

Learn More

15 Days Trial

Accept returns within fifteen (15) days of delivery. Click here for more information.

Learn More

1-Year Warranty

We provide 1-year warranty for all the electrical components.

Learn More

CE Certified

Our Bikes are all meeting the standard of CE certification.

Learn More

Motor	48V 250W Brushless Gear Hub Motor
Throttle	Haif-twist throttle (on the right side)
Display	LCD Display
Top Speed	25 km/h
Battery	18AH
Pedal Assist	5 Levels
Charger	2A Charger
Time of Charging	8-9 Hours

Rotin Pathfinder Pro (Europe)

LF Pro 2026

Spotlights

120 Kilometres

180 kg

Hydraulic

18AH

250 W

25 km/h

20x4"

7-Speed
