Rattan Pathfinder Pro (Europa)

Name: Rattan Pathfinder Pro (Europa)
Brand: Rattan
SKU: PF-BU
Price: 1399.0 EUR
Availability: InStock

26” Fat tire Mountain E-Bike, Full Suspension System, LCD Display, Powerful motor, 48V 18AH Battery, 120km max range, Double Crown Suspension Fork.

5.0 (104 )

€1.399,00

Free Domestic Shipping, No Tax

Pre-order, Ship In October 25th

Colore: Blu scuro

Versione

Variante

Secure Payment

See checkout for updated shipping info.

CE Certified

15 Days Trial

1-Year Warranty

Free Accessories included

Portapacchi posteriore Pathfinder Pro in rattan

€43,95

Free

Parafanghi completi per Pathfinder Pro

€114,95

Free

Fanale posteriore Pathfinder Pro in rattan

€26,95

Free

18AH Large Capacity Battery
48V Brushless Rear Hub Motor
120km average Range, Top Speed 25km/h
DUAL Hydraulic Disc Brake
FULL Suspension System
Weight: 81 lbs
5 Levels Pedal Assist
400lbs Payload Capacity
Shimano 7-speed gear shift system

Technical Specifications

Pathfinder Pro

Motore	Motore del mozzo con ingranaggi brushless da 48 V
Acceleratore	Haif-twist acceleratore (sul lato destro)
Display	Schermo LCD
Velocità massima	25 km/h
Batteria	18AH
Assistenza alla pedalata	5 livelli
Caricabatterie	Caricabatterie 2A
Tempo di ricarica	8-9 ore

Riflettori

1. Motore del mozzo posteriore brushless da 48 V
2. Batteria semi-integrata da 48 V 864 Wh 18 Ah
3. Forcella ammortizzata a doppia corona, sistema di sospensione completa
4. Schermo LCD
5. Caricabatterie da 2A
6. Lega 9/16" pedale della grande piattaforma
7. Comfort ergonomico
8. Pneumatici fuoristrada 26" X 4.0"
9. Sistema di cambio a 7 velocità
10. Freno idraulico anteriore da 180 mm e posteriore da 180 mm
11. Capacità di carico utile: 400 libbre
12. Autonomia: fino a 120 chilometri
13. Haif-twist acceleratore (sul lato destro)
14. Velocità massima: 25 km/h
15. Luce anteriore automatica integrata e luce posteriore integrata con funzionalità di indicatore di luce di stop

Overview

Features

Sizing

Reviews

Overview

Features

Sizing

Reviews

"Built for rough roads. Designed for smooth rides."

Lithium-Ion Battery

48V 18A

Max Range

Up to 120 km

Suspension System

Front and Mid-mounted

Max Torque

120 N.M

Height Recommend

5'5 - 6'6

Maximum Loading

400lbs

Lithium-Ion Battery

48V 18A

Max Range

Up to 120 km

Suspension System

Front and Mid-mounted

Max Torque

120 N.M

Height Recommend

5'5 - 6'6

Maximum Loading

400lbs

Enjoy up to 120 km per charge with sleek in-frame design and protected charging.

18Ah High-Capacity Integrated Battery

Longer Riding Range: 18Ah capacity delivers up to 80-120 km per charge (depending on assist level and terrain), significantly more than standard 13–15Ah batteries.
High Energy Density, Sleek Design: Internal battery layout keeps the frame clean and stylish while reducing wind resistance and improving weight distribution for better balance.
More Efficient Charging: With smart BMS to protect against overcharge, overheating, and extend battery lifespan (800+ charge cycles).

Delivers up to 120 Nm torque, boosts range by 15%, and runs quietly with durable IPX5 protection.

High-Torque Motor for Efficient Performance

High Torque Performance: Powerful motor delivers 120 Nm of torque, providing strong climbing ability and smooth acceleration even on steep hills.
Efficient Power Output: Maintains stable wattage under load for consistent performance and better energy efficiency, extending overall battery range by up to 15%.
Durable & Low Noise Design: Sealed motor structure offers IPX5+ water resistance, operates under <55 dB noise level, and supports 1,000+ hours of riding lifespan with minimal maintenance.

Deliver 20% stronger braking, up to 3 m shorter stopping distance, and long-lasting performance in all conditions.

180 mm Dual Hydraulic Disc Brakes

Stronger Braking Power: 180 mm rotors provide up to 20% more stopping force than 160 mm brakes, ensuring confident
Precision + Stability: Dual hydraulic system delivers consistent braking performance with 4× better modulation and shorter stopping distance (up to 2–3 meters less) in wet or dry conditions.
Low Maintenance, Long Lifespan: Enclosed hydraulic system reduces wear and keeps performance stable for 1,000+ braking cycles, requiring less frequent adjustment compared to mechanical brakes.

Absorbs 80% of vibrations, boosts traction by 30%, and supports up to 180 kg for smoother, safer rides.

Dual Suspension System for Superior Comfort

Full Suspension Comfort: Front fork + rear shock absorb up to 80% of road vibration, making rough terrain feel smooth and reducing rider fatigue on long rides.
Better Control & Stability: Dual suspension increases tire traction by 30%, allowing safer handling on bumps, gravel, and downhill paths.
High Travel & Load Capacity: Front travel up to 80–100 mm and rear shock support up to 180 kg (400 lbs), offering both performance and durability for different riding styles and rider weights.

Reduces impact stress by 40%, boosts traction by 25%, and supports up to 180 kg with long-term durability.

FOUR-Bar Linkage Frame for Smoother Suspension

Advanced Shock Absorption Structure: 4-bar linkage frame disperses impact forces across four pivot points, reducing frame stress by up to 40% compared to single-pivot designs.
Greater Stability & Handling: Multi-link geometry keeps the rear wheel in better contact with the ground, improving traction and cornering stability by 25% on uneven terrain.
High Load & Durability: Reinforced linkage design supports up to 180 kg (400 lbs) total weight and passes 50,000+ fatigue test cycles, ensuring long-term strength and reliability.

Color Display

Multifunctional Display

Rattan Ebikes custom color display with Energy indicator, pedal assist level / Speedometer, Odometer/headlight /walk mode and more.

Puncture Resisting

4.0 All-Terrain Tires

4.0" all-terrain fat tires deliver superior grip, shock absorption, and stability on pavement, gravel, sand, and snow.

LED Integrated

Bright Front & Rear light

Bright front & rear lighting system ensures 360° visibility and safer riding day or night.

Comfortable

Rear Suspension

Absorbs bumps and rough terrain, ensuring a smoother, more comfortable ride and better control.

Shimano 7-Speed

7-Speed Gear System

Offering smooth shifting and optimal cadence control for climbing hills, cruising flats, and riding efficiently in any terrain.

60 LBS Load Capacity

Sturdy Rear Rack

Provides reliable support for carrying up to 27 kg of cargo, making daily commuting and errands effortless.

Full Fenders

Durable Fenders

Keep you and your bike clean by effectively blocking mud, water, and debris on wet or muddy rides.

FAQ

New Bike, New Questions

Want to learn more about the Rattan? Check out our FAQs.

Get answers

What comes with the bike?

The bike comes with a battery, rear rack, charger, fenders, and front and rear lights. Other purchased accessories are shipped separately.

How heavy is this bike?

Pathfinder Pro - 81 lbs

What is the suitable height range for riding this bike?

The bike is suitable for the person from 5.5ft to 6.6ft (167cm to 200cm).

What road conditions are suitable for the Pathfinder Pro?

The Pathfinder Pro is built to conquer complex road conditions, rugged off-road trails, and long-distance commutes. Equipped with 26"x4" puncture-resistant fat tires and a full suspension system, it delivers unmatched stability and a smooth, comfortable ride.

Is this bike waterproof? Can it be ridden in the rain?

The Pathfinder Pro has basic waterproof performance (splash-proof design of the electronic control system), and there is no problem riding in light rain. However, it is not recommended to soak or expose it to heavy rain for a long time.

Is the sensor on this bike cadence or torque sensor?

It is cadence.

Are the brakes on this bike mechanical or hydraulic？

They are hydraulic brakes.

Should I Fully Discharge The Battery Before Charging?

No. Our batteries are equipped with built-in protection systems to prevent overcharging.

What Payment Methods Does The Website Support?

Klarna / Paypal / VISA / Venmo / Mastercard / Shop Pay / Google Pay / American Express / Diners Club / Discover

What is the warranty?

Rattan offers a one-year warranty on all e-bikes, for more specific warranties, please check our warranty policy. https://rattanebike.com/pages/warranty

What's your shipping policy?

We ship from our warehouse in Europe, and your order typically arrives within 3-10 days. For more information, please visit our Shipping Policy. https://rattanebike.com/pages/shipping-delivery-1
